စွမ်းဆောင်ရည်မြင့်မားသောခံနိုင်ရည်ရှိသောရာဘာခံနိုင်ရည်ရှိသောရော်ဘာစီတန်းထားသည့်သံမဏိပိုက်

（China Flange National Standard: GB/T 9119-2010）

No.

Specifications

Material No.

O.D.

ΦD1

I.D.

ΦD2

Wall Thickness t1

Liner Thickness t2

Length

PN10

1

DN100PN10L

R-GZ-G-1001

108

80

4

10

2000

2

DN125PN10L

R-GZ-G-1001

133

105

4

10

3000

3

DN150PN10L

R-GZ-G-1001

159

130

4.5

10

3000

4

DN200PN10L

R-GZ-G-1001

219

189

5

10

3000

5

DN250PN10L

R-GZ-G-1001

273

243

5

10

3000

6

DN300PN10L

R-GZ-G-1001

325

283

6

15

3000

7

DN350PN10L

R-GZ-G-1001

377

335

6

15

3000

8

DN400PN10L

R-GZ-G-1001

425

373

6

20

6000

9

DN450PN10L

R-GZ-G-1001

480

426

7

20

6000

10

DN500PN10L

R-GZ-G-1001

530

466

7

25

6000

11

DN600PN10L

R-GZ-G-1001

630

564

8

25

6000

12

DN700PN10L

R-GZ-G-1001

720

654

8

25

6000

13

DN800PN10L

R-GZ-G-1001

820

752

9

25

6000

No.

Specifications

Material No.

O.D.

ΦD1

I.D.

ΦD2

Wall Thickness t1

Liner Thickness t2

L

PN16

1

DN100PN16L

R-GZ-G-2001

108

80

4

10

2000

2

DN125PN16L

R-GZ-G-2001

133

105

4

10

3000

3

DN150PN16L

R-GZ-G-2001

159

129

5

10

3000

4

DN200PN16L

R-GZ-G-2001

219

187

6

10

3000

5

DN250PN16L

R-GZ-G-2001

273

241

6

10

3000

6

DN300PN16L

R-GZ-G-2001

325

281

7

15

3000

7

DN350PN16L

R-GZ-G-2001

377

333

7

15

3000

8

DN400PN16L

R-GZ-G-2001

425

369

8

20

6000

9

DN450PN16L

R-GZ-G-2001

480

424

8

20

6000

10

DN500PN16L

R-GZ-G-2001

530

462

9

25

6000

11

DN600PN16L

R-GZ-G-2001

630

560

10

25

6000

12

DN700PN16L

R-GZ-G-2001

720

648

11

25

6000

13

DN800PN16L

R-GZ-G-2001

820

746

12

25

6000

No.

Specifications

Material No.

O.D.

ΦD1

I.D.

ΦD2

Wall Thickness t1

Liner Thickness t2

L

PN25

1

DN100PN25L

R-GZ-G-3001

108

78

5

10

2000

2

DN125PN25L

R-GZ-G-3001

133

103

5

10

3000

3

DN150PN25L

R-GZ-G-3001

159

127

6

10

3000

4

DN200PN25L

R-GZ-G-3001

219

185

7

10

3000

5

DN250PN25L

R-GZ-G-3001

273

237

8

10

3000

6

DN300PN25L

R-GZ-G-3001

325

277

9

15

3000

7

DN350PN25L

R-GZ-G-3001

377

329

9

15

3000

8

DN400PN25L

R-GZ-G-3001

425

365

10

20

6000

9

DN450PN25L

R-GZ-G-3001

480

418

11

20

6000

10

DN500PN25L

R-GZ-G-3001

530

456

12

25

6000

11

DN600PN25L

R-GZ-G-3001

630

554

13

25

6000

12

DN700PN25L

R-GZ-G-3001

720

640

15

25

6000

13

DN800PN25L

R-GZ-G-3001

820

738

16

25

6000
